THE GABLES SERIES — NerdQaxe++ Rev6.1 6 TH/s

The NerdQaxe++ Revision 6.1 is the definitive quad-chip open-source Bitcoin solo miner. Four BM1370 chips running at 800 MHz push 6+ TH/s at roughly 103 watts — an efficiency of approximately 14.66 J/TH. At stock (600 MHz / 1150 mV), it delivers 4.82 TH/s at just 70.6 watts with ASIC temps near 48°C.

Rev6.1 is fuse-free, built on an improved PCB with better power regulation, and ships with XT30 connectors for more stable high-current delivery. Real-world community reports confirm stable 6–6.5 TH/s operation when overclocked.

This is the most powerful compact Bitcoin solo miner currently available in the open-source ecosystem.

Specs:
ASIC Chip: 4x BM1370
Hashrate: 4.82 TH/s stock / 6–6.5 TH/s overclocked
Power Consumption: ~70.6W stock / ~103W overclocked
Efficiency: ~14.66 J/TH (stock)
ASIC Temp (stock): ~48°C
VRM Temp (stock): ~41°C
Connectivity: 2.4 GHz Wi-Fi
Firmware: AxeOS
Display: TFT color screen
Power Connector: XT30
Power Input: 12V DC / 10A minimum

Setup: Same as NerdQaxe++ above.
